REPLACEMENT PARTS USER-REPLACEABLE PARTS
AB8172 POT NUT BK (19 places -
under knobs)
AJ5320 XONE FADER KNOB
(3 places - faders)
AJ7304 XONE KNOB
(SML) (11 places)
AJ7305 XONE KNOB
(LGE) (8 places)
AB9256 2.5x9 AB TORX (10 places) on
front panel and rear chassis panel
The diagram above shows all of the replacement parts that can be ordered from your local
technical support, or direct from Allen & Heath, for the Xone:23C. When ordering please
quote the part number(s) of the required parts - this makes life easier for us!
See page 18 for information on replacing the crossfader, and for replacement crossfader as-
sembly numbers.
AB9037 M3 x 85 CSK (12 places)
AJ9422 17cm DVS conversion harness
(two per mixer)
