Allen & Heath 10 XONE:42 User Guide
MIC / USB INPUT CHANNEL
7
8
6
Channel Level Control
The channel signal level can be adjusted from fully off to
fully on.
8
Channel On Switch
Press the Channel On switch to send the channel audio
to the mix. When selected, the green LED indicator will
illuminate.
6
7
Cue Switch
Press the Cue switch to listen to the channel pre-fade
signal in the headphones and view its level on the main
meters. The red LED indicator next to the switch lights
when selected. The Cue LED indicator in the monitor
section also lights to warn that you are monitoring the
channel signal rather than the main mix. Press the
switch again to deselect cue.
