Page #7 background imageLoading...
Page #7 background image
Allen & Heath 7 XONE:42 User Guide
Dimensions and Weights
The console is fitted with rubber feet for desktop operation.
Width Height Depth Weight
Mixer 305 mm (12“) 84 mm (3.3“) 358 mm (14”) 5 kg (11 lbs)
Packed 490 mm (19.5”) 205 mm (8.1”) 450 mm (17.7”) 7 kg (15.4 lbs)
SPECIFICATIONS
Nom / max output levels Main Mix +4dBu +27dBu
Booth 0dBu +22dBu
X:FX Send 0dBu +20dBu
Record Out -10dBV +10dBV
Internal headroom Channels +22dB
Frequency response +/-0.5dB 10Hz - 20kHz
Distortion < 0.03% THD+noise @1kHz
Crosstalk < -90dB inter-channel
Mic EIN 22Hz-22kHz -126dB 150 ohm source
Residual noise Mix 1 -94dBu
Booth -101dBu
X:FX -92dBu
Rec -95dBu
Mix noise Mix 1 -80dBu (-84dB S/N)
Booth -84dBu (-82dB S/N)
X:FX -88dBu (-84dB S/N)
Rec -90dBu
Channel meters Peak reading 9 LED -20dB to +10dB
Main meters Peak reading 9 LED -20dB to +10dB
Mic EQ 2-Band +/-12dB
Channel EQ 3-Band +6dB / total kill
Channel fader 60mm stereo VCA, < -90dB shutoff
Crossfader 45mm stereo VCA - replaceable
Filters Stereo VCF, analogue
Consumption 30W max
