ALLEN & HEATH XONE:43C Quick Start Guide

1
# XONE:43C Control Function
1 ON/OFF Power ON/OFF switch
2 KENISNGTON LOCK Connect a Kensington lock to secure mixer
3 PHONO/LINE Connect RCA phono or line level inputs
4 CHANNEL INPUT SOURCE Select channel input source (Phono/Line)
5 GROUNDING POST Connect grounding wire from turntables
6 BOOTH Booth RCA output
7 RECORD Record RCA output
8 X-FX SEND Send out to X-FX unit
9 X-FX RETURN Return in from X-FX unit
10 MASTER Master XLR output
11 X-LINK Connect to link to another X-LINK device
12 USB Connect USB to your computer
13 DC POWER IN Connect DC power cable
432
678910111213
5
Mixer
PHONO
LINE
PHONO
LINE
PHONO
LINE
PHONO
LINE
MASTER
RECORD
X:FX
RTNS ND
X:FX
BOOTH

ALLEN & HEATH XONE:43C Specifications

General

Sample rate	96 kHz
Channels quantity	16 channels
Digital sound processing	24 bit
Line Signal-to-Noise Ratio (SNR)	20 dB
Total Harmonic Distortion (THD)	0.05 %
Microphone in	Yes
Headphone connectivity	3.5 mm
Product color	Black
Video capability	No
Power consumption (typical)	30 W
Equalizer bands quantity	3

Weight and Dimensions

Depth	370 mm
Width	320 mm
Height	110 mm
Weight	5200 g
