ALLEN&HEATH XONE:DX service manual AP7894_5 Page - 8 - of 12
Corner plastic
moulding
Outside AA7717-
Inside AA7717-1
Ground
terminal post
AL8106
RCA phono
AL0556
5pin DIN MIDI
AL3962
DC power socket
AL6849
USB
AL6096
RCA phono
gold
AL4977
XLR male
AL2413
Knob small
black white line
AJ7345
XLR female
AL2414
Headphone jack
large AL0328
Headphone jack
small AL5323
