22 XONE:V6 User Guide
483mm (19")
441mm (17 3/8")
178mm (7")
4U
181mm (7 1/8")
256mm (10")
Allow 75mm (3") min clearance for connectors
101.6mm (4")
4x M6 rack bolts
76mm (3")
