Allen-Bradley 1395 User Manual

3-12 Malfunctions Not Indicated by a Fault
Figure 3.1 Waveform 1 - Encoder Phases A (TP15) and B (TP12), Forward (CCW)
Figure 3.2 Waveform 2 - Encoder Phases A (TP15) and B (TP12), Reverse (CW)
Figure 3.3 Waveform 3 - Encoder Signals A (TB3–20) and A NOT (TB3–19)
Figure 3.4 Waveform 4 - Encoder Signals B (TB3–18) and B NOT (TB3–17)
CH2 gnd
CH1 gnd
CH2 gnd
CH1 gnd
