Allen-Bradley 1395 - Page 94

A-4 Parameter List/Record
Table A.C Fast Sink Parameters
Parameter
Number Description Default Value
Linked To
Parameter
150 LOGIC COMMAND 1
BIT 0 = RUN REFERENCE A
BIT 1 = RUN REFERENCE B
BIT 2 = RUN REFERENCE C
BIT 3 = MOP INCREMENT
BIT 4 = MOP DECREMENT
BIT 5 = RAMP DISABLE
BIT 6 = MOP RATE 1
BIT 7 = MOP RATE 2
BIT 8 = AUTO/MANUAL
BIT 9 = JOG 2
BIT 10 = JOG 1
BIT 11 = NORMAL STOP
BIT 12 = START
BIT 13 = CLOSE CONTACTOR
BIT 14 = CLEAR FAULT
BIT 15 = PROCESS TRIM
151 LOGIC COMMAND 2
BIT 0 = RUN REFERENCE A
BIT 1 = RUN REFERENCE B
BIT 2 = RUN REFERENCE C
BIT 3 = MOP INCREMENT
BIT 4 = MOP DECREMENT
BIT 5 = RAMP DISABLE
BIT 6 = MOP RATE 1
BIT 7 = MOP RATE 2
BIT 8 = AUTO/MANUAL
BIT 9 = JOG 2
BIT 10 = JOG 1
BIT 11 = NORMAL STOP
BIT 12 = START
BIT 13 = CLOSE CONTACTOR
BIT 14 = CLEAR FAULT
BIT 15 = PROCESS TRIM
152 LOGIC COMMAND 3 200
BIT 0 = RUN REFERENCE A
DHT Parameter
200 Hard Linked
BIT 1 = RUN REFERENCE B
BIT 2 = RUN REFERENCE C
BIT 3 = MOP INCREMENT
BIT 4 = MOP DECREMENT
BIT 5 = RAMP DISABLE
BIT 6 = MOP RATE 1
BIT 7 = MOP RATE 2
BIT 8 = AUTO/MANUAL
BIT 9 = JOG 2
BIT 10 = JOG 1
BIT 11 = NORMAL STOP
153 LOGIC COMMAND 1
154 BIT 0 = RUN REFERENCE A
