Allen-Bradley 1395 - Page 95

Parameter List/Record A-5
Table A.D Parameter Values
156 BIT 1 = RUN REFERENCE B
157 BIT 2 = RUN REFERENCE C
159 BIT 3 = MOP INCREMENT
160 BIT 4 = MOP DECREMENT
161 BIT 5 = RAMP DISABLE
162 BIT 6 = MOP RATE 1
163 BIT 7 = MOP RATE 2
164 BIT 8 = AUTO/MANUAL
165 BIT 9 = JOG 2
166 BIT 10 = JOG 1
Parameter
Number Description Value PLC Reference
600 VELOCITY PARAM 1 SEL (PAR 163)
601 VELOCITY PARAM 2 SEL (PAR 164)
602 VELOCITY PARAM 3 SEL (PAR 165)
603 VELOCITY PARAM 4 SEL (PAR 166)
606 BASE MOTOR SPEED
607 REVERSE SPEED LIMIT
608 FORWARD SPEED LIMIT
609 ENCODER PPR
610 RATED MOTOR VOLTAGE
611 MOTOR ARMATURE FLA
612 RATED FIELD MOTOR CURRENT
613 MOTOR INERTIA
614 ARMATURE RESISTANCE
615 RATED ARMATURE BRIDGE CURRENT
616 RATED FIELD BRIDGE CURRENT
617 RATED AC LINE VOLTAGE
620 SYSTEM RESET SELECT
0 = SYSTEM RESET
1 = NORMAL STOP
621 FEEDBACK DEVICE TYPE
0 = ENCODER
1 = ARMATURE VOLTS
2 = ANALOG TACH
3 = NO FDBK
622 CONTACTOR TYPE
AC = 0 (INTERRUPTS AC SUPPLY)
DC = 1 (INTERRUPTS DC ARM CIRCUIT)
623 HARD FAULT SELECT
BIT 0 = SCR OVERTEMP
BIT 1 = MOTOR OVERTEMP
BIT 2 = OVERLOAD TRIP
BIT 3 = STALL
BIT 4 = AC VOLTAGE OUT OF TOLERANCE
BIT 5 = WAITING SAFE ARM VOLTS
BIT 6 = WAITING ZERO CURRENT
BIT 7 = BRIDGE OVERLOAD
624 MAINTAINED START
0 = MOMENTARY
1 = MAINTAINED
