Parameter List/Record A-9
Table A.E Internal Configuration Parameters
Table A.F Trend Function Parameters
Table A.G Trend Buffer #1 Parameters
Table A.H Trend Buffer #2 Parameters
Constant
Internal
Parameter Linked to Fast Sink Parameter Description
840 10
841 11
842 12
843 13
844 14
Parameter
Number Description Value PLC Reference
900 Trend Sign Value
901 Trend Sign Value
902 Trend Sign Value
903 Trend Sign Value
904 Trend Logic Value
905 Trend Logic Value
906 Trend Logic Value
907 Trend Logic Value
908 Trend Unsign Value
909 Trend Unsign Value
Description
Parameter
Number Parameter Range Parameter Value
Trend Buffer #1 is linked to parameter:
The output of trend buffer #1 is linked to parameter:
Trend 1 operand parameter X 910 1-947
Trend 1 operand parameter Y 911 1-947
Trend 1 operator 912 GT, LT, EQ, AND, NAND, OR, NOR
Trend 1 sample rate 913 0.0004-30 seconds
Trend 1 post samples 914 0-99
Trend 1 multiple trigger 915 OFF, ON
Trend 1 enable 916 OFF, ON
Trend 1 output rate 917 0.0004-30 seconds
Description
Parameter
Number Parameter Range Parameter Value
Trend Buffer #2 is linked to parameter:
The output of trend buffer #2 is linked to parameter:
Trend 2 operand parameter X 920 1-947
Trend 2 operand parameter Y 921 1-947
Trend 2 operator 922 GT, LT, EQ, AND, NAND, OR, NOR
Trend 2 sample rate 923 0.0004-30 seconds
Trend 2 post samples 924 0-99
Trend 2 multiple trigger 925 OFF, ON
Trend 2 enable 926 OFF, ON
Trend 2 output rate 927 0.0004-30 seconds
