Allen-Bradley 140G Series User Manual

2
9 Nm
max 0.75"/19mm
43 Nm
381 lb-in
80 lb-in
min 1.22"/31 mm
CH 10
CH 5
LENGTH M
55 mm (2.17") M 6
Flexible Cable
AWG/kcmil
mm
2
-
MIN 2/0 AWG 70 -
MAX 400kcmil 185 -
MIN 2/0 AWG 70 -
MAX 350kcmil 185 -
CuAl
Cu
Stranded Cable
Example for 140G-M-TLA33
(3)
Flex ible C able
A W G /k c m il
m m
2
-
M IN 250 k c m il 120 -
M A X 500k c m il 240 -
M IN 3/0 A W G 85 -
M A X 350k c m il 185 -
CuA l
Cu
S tranded Cable
Example for 140G-M-TLA23
5 Nm
44.3 lb-in
LENGTH M
20 mm (0.79") M 6
LENGTH M
35 mm (1.38") M 6
max 0.84"/21.5mm
min 0.94"/24mm
31 Nm
274 lb-in
CH 8
1
5
4
6
7
8
1.5 Nm
13.3 lb-in
1.5 Nm
13.3 lb-in
1.1 Nm
9.7 lb-in
LENGTH dia.
1 2 mm (0.47") 3.5
DIR 1000479R0824 Version 04

Allen-Bradley 140G Series Specifications

General

Series	140G
Poles	1, 2, 3, 4
Standards	UL 489, CSA C22.2 No. 5, IEC 60947-2
Type	Molded Case Circuit Breaker
Frame Sizes	G
Amperage	10A to 3000A
Trip Type	Thermal-Magnetic, Electronic
Mounting	Fixed or Plug-in
Voltage Ratings	Up to 690V AC
