Allen-Bradley 1746 Series User Manual

Discrete I/O Modules 15
Publication 1746-IN005A-US-P
Table 10:Specifications for Input Module 1746-IN16
Specification 1746-IN16
(1)
(1)Removable Terminal Block.
Voltage Category 24V ac/dc Signal Input
Number of Inputs 16
Points per Common 16
Operating Voltage
dc 10 to 30V dc (sinking)
ac 10 to 30V ac
Backplane Current
Consumption
5V dc 0.085A
24V dc 0.0A
Signal Delay (max.)
dc
on = 15 ms
off = 15 ms
ac
on = 25 ms
off = 25 ms
Off State Voltage (max.)
dc 3.0V dc
ac 3.0V ac
Off State Current (max.)
dc 1 mA
ac 1 mA
Nominal Input Current
dc 8 mA at 24V dc
ac 8 mA at 24V ac
Inrush Current (max.) 0.02A (ac only)
Allen-Bradley Spares

Allen-Bradley 1746 Series Specifications

General

Category	I/O Systems
Shock Resistance	30G
Backplane Current	Varies by module. Refer to individual module specifications.
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	Varies by module. Refer to individual module specifications.
Series	Allen-Bradley 1746
Module Type	Digital/Analog I/O Modules
