Discrete I/O Modules 23
Publication 1746-IN005A-US-P
Table 15:Specifications for Output Modules 1746-OV8, -OV16, and -OVP16
Specification
Catalog Number 1746-
OV8 OV16
(1)
(1)Removable Terminal Block.
OVP16
(1)(2)(3)
(4)
(2)A fused common and blown fuse LED are provided on this module. See “Fuse Protection
and Blown Fuse Diagnostics” on page 32.
(3)Use the following ID Code when configuring your system with programming software or
the HHT: 1746-OVP16 = 2922.
(4)Certified for Class 1, Division 2 hazardous location by CSA.
Number of Outputs 81616
Points per Common 81616
Voltage Category 24V dc Signal Output
Operating Voltage (V dc) 10 to 50 (sink)
20.4 to 26.4
(sink)
Backplane
Current
Consumption
5V dc 0.135A 0.270A 0.250A
24V dc 0.0A
Signal Delay (max.). Resistive
Load.
on = 0.1 ms
off = 1.0 ms
on = 0.1 ms
(5)
off = 1.0 ms
(5)Fast turn-off modules (1746-OB6EI, -OBP8 Series B and later, -OB16E Series B and
later, -OBP16, and -OVP16) provide fast OFF delay for inductive loads. Comparative
OFF delay times for 1746-OB8/-OV8 and fast turn-off modules; when switching Bulletin
100-B110 (24Ws sealed) contactor, are: 1746-OB8/-OV8 OFF delay = 152 ms; fast turn-
off modules OFF delay = 47 ms.
Off State Leakage (max.)
(6)
1 mA
Load Current (min.) 1 mA
Continuous Current per Point
(7)
1.0A at 30°C
0.50A at
60°C
0.50A at
30°C
0.25A at
60°C
1.5A at 30°C
(8)
1.0A at 60°C
Continuous Current per Module
8.0A at 30°C
4.0A at 60°C
6.4A at
0 to 60°C
On State Voltage Drop (max.) 1.2V at 1.0A 1.2V at 0.5A 1.0V at 1.0A
Surge Current per Point
(9)
3.0A for 10 ms
4.0A for 10
ms
(10)
