Allen-Bradley 1746 Series User Manual

Discrete I/O Modules 55
Publication 1746-IN005A-US-P
Figure 22:Wiring Diagram (1746-IO12)
Figure 23:Wiring Diagram (1746-IO12DC)
OUT 0
OUT 2
OUT 3
OUT 4
OUT 5
NOT
USED
IN 1
IN 2
IN 3
IN 4
AC COM
NOT
USED
CR
CR
NOT
USED
OUT 1
NOT
USED
IN 5
VAC-VDC
IN 0
100/120V ac
L1
L2
L2 or -DC
L1 or +DC
V ac/dc
1746-IO12
100/120V ac INPUT - RELAY
OUT 0
OUT 2
OUT 3
OUT 4
OUT 5
NOT
USED
IN 1
IN 2
IN 3
IN 4
DC COM
NOT
USED
CR
CR
NOT
USED
OUT 1
NOT
USED
IN 5
VAC-VDC
IN 0
-DC
10-30V dc
+DC
L2 or -DC
L1 or +DC
V ac/dc
1746-IO12DC
24V dc INPUT - RELAY OUTPUT
Allen-Bradley Spares

Allen-Bradley 1746 Series Specifications

General

Category	I/O Systems
Shock Resistance	30G
Backplane Current	Varies by module. Refer to individual module specifications.
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	Varies by module. Refer to individual module specifications.
Series	Allen-Bradley 1746
Module Type	Digital/Analog I/O Modules
