Rockwell Automation Publication 1769-IN015D-EN-P - October 2017 5
Compact I/O End Caps/Terminators
1769-ECL Left End Cap
1769-ECL Dimensions
1
2
118 mm
(4.6 in.)
15 mm
(0.59 in.)
87 mm
(3.43 in.)
