Rockwell Automation Publication 1769-UM021G-EN-P - October 2015 157
Use I/O Modules with CompactLogix 5370 L1 Controllers Chapter 7
Figure 24 - CompactLogix 5370 L1 Controllers Embedded Digital Output Point Wiring Diagram
Load
Load
Terminal Block with Bus Connector Strip
Load
Load
Load
