Allen-Bradley 1769-L24ER-QB1B User Manual

234 Rockwell Automation Publication 1769-UM021G-EN-P - October 2015
Chapter 8 Use I/O Modules with CompactLogix 5370 L2 Controllers
To see the fault description on the Connection tab in Module Properties dialog
box, complete these steps.
1. In the I/O Configuration, right-click the faulted I/O module and
choose Properties.
2. Click the Connection tab and use the fault description, in the Module
Fault section, to diagnose the issue.
3. Click OK to close the dialog box and remedy the issue.
