Chapter 3 Install the CompactLogix 5370 L3 Controller
System Dimensions
This graphic shows the system dimensions.
132 mm
(5.20 in.)
118 mm
(4.65 in.)
55 mm
(2.17 in.)
70 mm
(2.76 in.)
35 mm
(1.38 in.)
35 mm
(1.38 in.)
35 mm
(1.38 in.)
35 mm
(1.38 in.)
35 mm
(1.38 in.)
52.5 mm
(2.07 in.)
105 mm
(4.13 in.)
18 mm
(0.71 in.)
