Configurable NAT Router 7
Rockwell Automation Publication 1783-PC017B-EN-P - May 2016
End of Life Disposal
中国 RoHS 指令符合性表
Specifications
Additional Resources
These documents contain additional information concerning related products from Rockwell Automation.
At the end of its life, collect this equipment separately from any unsorted municipal waste.
China RoHS Compliance Table
部件名称
Component Name
有害物质
Hazardous substances
鉛
Lead
(Pb)
汞
Mercury
(Hg)
鎘
Cadmium
(Cd)
六价铬
Hexavalent
Chromium
(Cr(VI))
多溴联苯
Polybrominated
Biphenyls
(PBB)
多溴二苯醚
Polybrominated
Diphenyl
Ethers
(PBDE)
外壳
Housing
OO O O O O
印刷电路板组件
Printed Circuit Board Assemblies
XO O O O O
金属部件
Metal Components
OO O O O O
本表格依据 SJ/T 11364 的规定编制。This table is made per guidance of SJ/T 11364
O: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。
O: Indicates that this hazardous substance contained in all of the homogeneous materials for the part is below the limit requirement in GB/T 26572.
X: 表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。
X: Indicates that this hazardous substance contained in at least one of the homogeneous materials used for this part is above the limit requirement in GB/T 26572.
( 企业可在此处，根据实际情况对上表中打 “X” 的技术原因进行进一步说明。)
(According to actual situation, extra explanations can be given here for the technical reasons of items with "X".)
Attribute 1783-NATR
Power consumption, max 3 W
DC power supply input 20.4…27.6V DC/limited voltage
Ethernet connections • RJ45 connector according to IEC 60603-7, 2 or 4 pair
• Category 5e minimum cable according to TIA 568-B.1
• Category 5 cable according to ISO/IEC 24702
Weight, approx 0.38 kg (0.84 lb)
Wire size
Single wire, max:
Double wire, max:
0.33…3.3 mm² (22…12 AWG) stranded copper wire rated at 75 °C (167 °F), or greater, 1.2 mm (3/64 in.) insulation
0.33…1.3 mm² (22…16 AWG) solid copper wire rated at 75 °C (167 °F), or greater, 1.2 mm (3/64 in.) insulation
Torque 0.6…0.8 N•m (5…7 lb•in) on power connector
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold)
IEC 60068-2-2 (Test Bd, Operating Dry Heat)
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
-25…+70 °C (-13…+158 °F)
Temperature, surrounding air, max 70 °C (158 °F)
Temperature code T4
Current rating 150 mA
Resource Description
Stratix Ethernet Switches Specifications, publication 1783-TD001
Contains technical specifications, environmental specifications, certifications, and other information that
pertains to Stratix™ Ethernet switches.
Configurable NAT Router User Manual, publication 1783-UM008
Provides information on how to install, configure, and operate the 1783-NATR router.
