6
Publication 1785-6.2 March 1998 For A-B Internal Use Only
If you received an error:
When the flash download begins:
• the processor’s COMM LED blinks green
• the processor’s PROC LED blinks red/green
• a percent complete status (0 - 100) appears in the middle
of the screen that indicates how much of the flash update
is complete
6. Wait for the flash update to complete. The upgrade should take
about 5 minutes to complete.
When the download is complete the status bar will be at 100%
and the screen will display this message:
Processors Flash
Update Completed. Press Any Key to Continue.
If you received this error: Do this:
Processor not connected. a. Make sure the keyswitch is in Program
mode.
b. Make sure the processor power is on.
c. Check the serial cable.
d. Verify the COM port being used by the
computer.
e. Return to item 3, step 3 on page 5 and
repeat this section.
Target processor does
not match script file.
a. Check the name of the script file.
b. Make sure you are connected to the correct
type and series of processor.
c. Return to item 3, step 3 on page 5 and
repeat this section.
Firmware series stated
in script file does not
match PLC.
a. Make sure you are connected to the correct
type and series of processor.
b. Return to item 3, step 3 on page 5 and
repeat this section.
No script files found. a. Make sure you copied all files from the
firmware upgrade diskette to the c:\flash
hard drive directory as described in item 2,
step 2 on page 4.
b. Make sure you selected the catalog number
of the flash upgrade you want to
download to the processor on the flash
upgrade catalog number selection
screen. Do not select the catalog number
of the processor you currently have.
c. Return to item 3, step 3 on page 5 and
repeat this section.
