16 FLEX I/O DC Input, Output, and Input/Output Analog Modules
Publication 1794-IN106D-EN-E - January 2014
Environmental Specifications
Attribute 1794-IE12 1794-OE12 1794-IE8XOE4
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20...60 °C (-4...140 °F)
Temperature,
nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):
-40...85 °C (-40...185 °F)
Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Nonoperating Damp Heat):
5...95% noncondensing
Vibration IEC60068-2-6 (Test Fc, Operating):
5 g @ 10...500 Hz
Shock, operating IEC60068-2-27 (Test Ea, Unpackaged shock):
30 g
Shock, nonoperating IEC60068-2-27 (Test Ea, Unpackaged shock):
50 g
Emissions CISPR 11:
Group 1, Class A
ESD immunity EC 61000-4-2:
6 kV contact discharges
8 kV air discharges
Radiated RF immunity IEC 61000-4-3:
10V/m with 1 kHz sine-wave
80% AM from 80...2000 MHz
10V/m with 200 Hz 50% Pulse
100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse
100% AM @ 1890 MHz
10V/m with 1 kHz sine-wave
80% AM from 2000...2700 MHz
IEC 61000-4-3:
10V/m with 1 kHz sine-wave
80% AM from 80...2000 MHz
10V/m with 200 Hz 50% Pulse
100% AM @ 900 MHz
10V/m with 200 Hz 50% Pulse
100% AM @ 1890 MHz
3V/m with 1 kHz sine-wave
80% AM from 2000...2700 MHz
EFT/B immunity IEC 61000-4-4:
±4 kV @ 5 kHz
on power ports
±4 kV @ 5 kHz
on shielded
signal ports
IEC 61000-4-4:
±4 kV @ 5 kHz
on power ports
±2 kV @ 5 kHz
on shielded
signal ports
IEC 61000-4-4:
±4 kV @ 5 kHz on power ports
±4 kV @ 5 kHz on shielded
signal ports
Conducted RF immunity IEC 61000-4-6:
10V rms with 1 kHz sine-wave 80% AM from 150 kHz...80 MHz
