32 Rockwell Automation Publication 2080-UM001B-EN-E - November 2011
Appendix A Specifications
Micro810 High Current Relay Chart
Maximum
Volts
IEC 947 Amperes Amperes
Continuous
Volt-Amperes
Make Break Make Break
120V AC AC-15 30 A 3 A 8 A 3600 VA 360 VA
240V AC AC-15 15.0 A 1.5 A 8 A 3600 VA 360 VA
125V DC DC-13 0.22 A 1.0 A 28 VA
250V DC DC-13 0.11 A 1.0 A 28 VA
24V DC DC-13 1.2 A 5.0 A 28 VA
