Publication 2098-IN003E-EN-P — April 2004
C-4 Catalog Numbers and Accessories
Cables
Use the following tables to identify motor power, feedback, interface,
and brake cables for your Ultra3000 drive. Length of cable xx is in
meters. Refer to your Allen-Bradley representative for available cable
lengths.
Motor Power Cables
Description Catalog Number
H-Series, 230V, non-flex, 16 AWG, straight 2090-XXNPH-16Sxx
H-Series, 230V, non-flex, 16 AWG, right angle 2090-UXNPAH-16Rxx
H-Series, 230V, non-flex, 6 AWG, straight 2090-UXNPAH-6Sxx
H-Series, 230V, non-flex, 6 AWG, right angle 2090-UXNPAH-6Rxx
H and F-Series, 230V, non-flex, 14 AWG, straight 2090-XXNPHF-14Sxx
H and F-Series, 230V, non-flex, 14 AWG, right angle 2090-UXNPAHF-14Rxx
H and F-Series, 230V, non-flex, 10 AWG, straight 2090-UXNPAHF-10Sxx
H and F-Series, 230V, non-flex, 10 AWG, right angle 2090-UXNPAHF-10Rxx
H and F-Series, 230V, non-flex, 8 AWG, straight 2090-UXNPAHF-8Sxx
H and F-Series, 230V, non-flex, 8 AWG, right angle 2090-UXNPAHF-8Rxx
MP-Series (MPL/MPG), 230/460V, non-flex, 16 AWG, straight
2090-XXNPMP-16Sxx
1326AB (M2L/S2L), 460V, non-flex, 16 AWG, straight
MP-Series (MPL/MPG), 230/460V, non-flex, 14 AWG, straight 2090-XXNPMP-14Sxx
MP-Series (MPL/MPG), 230/460V, non-flex, 10 AWG, straight
2090-XXNPMP-10Sxx
1326AB (M2L/S2L), 460V, non-flex, 10 AWG, straight
MP-Series (MPL/MPG), 230/460V, non-flex, 8 AWG, straight 2090-XXNPMP-8Sxx
MP-Series (MPF), 230/460V, non-flex, 16 AWG, straight 2090-XXNPMF-16Sxx
MP-Series (MPF), 230/460V, non-flex, 14 AWG, straight 2090-XXNPMF-14Sxx
MP-Series (MPF), 230/460V, non-flex, 10 AWG, straight 2090-XXNPMF-10Sxx
N-Series, 230V, non-flex, 16 AWG, straight 2090-XXNPN-16Sxx
N-Series, 230V, non-flex, 16 AWG, right angle 2090-UXNPAN-16Rxx
Y-Series, 230V, non-flex, 16 AWG, straight 2090-XXNPY-16Sxx
