Allen-Bradley 20A User Manual

28 Rockwell Automation Publication PFLEX-AT001L-EN-P - September 2017
Chapter 3 Evaluating the PowerFlex 7-Class Internal Resistor
Figure 8 - PowerFlex 70 – 480 Volt, Frame C
Figure 9 - PowerFlex 70 – 480 Volt, Frame D
0 1 2 3 4 5 6 7 8 9 101112131415161718192021222324252627282930
Decel Time (Seconds)
% Peak Power
0
200
400
600
800
1000
1200
1400
1600
1800
2000
2200
2400
2600
2800
3000
480V Frame C
0 1 2 3 4 5 6 7 8 9 101112131415161718192021222324252627282930
Decel Time (Seconds)
% Peak Power
0
200
400
600
800
1000
1200
1400
1600
1800
2000
2200
2400
2600
2800
3000
480V Frame D
