Allen-Bradley 20A User Manual

Rockwell Automation Publication PFLEX-AT001L-EN-P - September 2017 31
Evaluating the PowerFlex 7-Class Internal Resistor Chapter 3
Figure 14 - PowerFlex 700 – 240 Volt, Frame 2
Figure 15 - PowerFlex 700 – 480 Volt, Frame 0
0
200
400
600
800
1000
1200
1400
1600
1800
2000
2200
2400
2600
2800
3000
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
240V Frame 2
Decel Time (Seconds)
% Peak Power
0
200
400
600
800
1000
1200
1400
1600
1800
2000
2200
2400
2600
2800
3000
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
400V Frame 0
Decel Time (Seconds)
% Peak Power
