48 Rockwell Automation Publication PFLEX-AT001L-EN-P - September 2017
Chapter 4 Selecting An External Resistor for PowerFlex 7-Class Drives
40.00 1800 82100 PR40R1K80 PowerOhm
40.00 1800 109900 PRT40R1K8 PowerOhm
40.00 2000 114700 PF40R2K00 PowerOhm
40.00 3150 177100 PR40R3K15 PowerOhm
40.00 3200 277000 PF40R3K20 PowerOhm
40.00 4000 105000 T40R4K0 PG/IPC
40.00 4000 439600 PRT40R4K0 PowerOhm
40.00 4000 448800 PF40R4K00 PowerOhm
40.00 4050 273300 PR40R4K05 PowerOhm
40.00 5850 438600 PR40R5K85 PowerOhm
40.00 6000 727000 PF40R6K00 PowerOhm
40.00 7200 718000 PR40R7K20 PowerOhm
40.00 10000 309000 T40R10K0 PG/IPC
40.00 10000 403000 PRT40R10K0 PowerOhm
40.00 10240 414500 PF40R10K2 PowerOhm
40.00 10240 445700 PR40R10K2 PowerOhm
40.00 11000 333000 T40R11K0 PG/IPC
40.00 11000 403000 PRT40R11K0 PowerOhm
40.00 11429 440000 PF40R11K4 PowerOhm
40.00 16000 521000 T40R16K0 PG/IPC
40.00 16000 638700 PF40R16K0 PowerOhm
40.00 16000 649900 PRT40R16K0 PowerOhm
40.00 17000 574000 T40R17K0 PG/IPC
40.00 17000 649900 PRT40R17K0 PowerOhm
40.00 19000 568000 T40R19K0 PG/IPC
40.00 19000 649900 PRT40R19K0 PowerOhm
40.00 22000 1099600 PRT40R22K0 PowerOhm
40.00 22000 1202000 T40R22K0 PG/IPC
40.00 22858 1130600 PF40R22K8 PowerOhm
36.00 Ohms
36.00 400 12900 PF36R400W PowerOhm
36.00 800 32400 PF36R800W PowerOhm
36.00 1200 77000 PF36R1K20 PowerOhm
36.00 1600 103200 PF36R1K60 PowerOhm
36.00 2000 99000 PF36R2K00 PowerOhm
36.00 2400 79200 PF36R2K40 PowerOhm
36.00 4000 395700 PF36R4K00 PowerOhm
36.00 4400 399000 PF36R4K40 PowerOhm
36.00 9216 414500 PF36R9K21 PowerOhm
36.00 11298 316618 555-11A PG/IPC
36.00 16517 449907 555-11 PG/IPC
36.00 16863 449907 550-11A PG/IPC
36.00 19044 1064100 PF36R19K0 PowerOhm
36.00 24978 1321116 550-11 PG/IPC
35.00 Ohms
35.00 1200 74700 PR5505-11A PowerOhm
35.00 2000 96100 PR5505-11 PowerOhm
35.00 2800 242300 PR5510-11A PowerOhm
35.00 3600 392600 PR5510-11 PowerOhm
35.00 4000 153800 PR552-11A PowerOhm
35.00 5058 157272 552-11A PG/IPC
35.00 5600 125600 PR552-11 PowerOhm
35.00 6423 249757 552-11 PG/IPC
35.00 11340 384900 PR555-11A PowerOhm
35.00 18515 940200 PR555-11 PowerOhm
35.00 23660 1274300 PR550-11 PowerOhm
Ohms Watts Watt Seconds Catalog Manufacturer
