Chapter 4 Selecting An External Resistor for PowerFlex 7-Class Drives
21.00 Ohms
21.00 400 18900 PF21R400W PowerOhm
21.00 800 47100 PF21R800W PowerOhm
21.00 1200 57700 PF21R1K20 PowerOhm
21.00 1600 75400 PF21R1K60 PowerOhm
21.00 2000 143600 PF21R2K00 PowerOhm
21.00 2400 107700 PF21R2K40 PowerOhm
21.00 3200 373400 PF21R3K20 PowerOhm
21.00 4000 240800 PF21R4K00 PowerOhm
21.00 5626 236100 PF21R5K62 PowerOhm
21.00 7426 234800 PF21R7K42 PowerOhm
21.00 8400 319400 PF21R8K40 PowerOhm
21.00 11251 564200 PF21R11K2 PowerOhm
21.00 17661 1694600 PF21R17K6 PowerOhm
21.00 22501 2282000 PF21R22K5 PowerOhm
21.00 33600 5992900 PF21R33K6 PowerOhm
21.00 45001 2394200 PF21R45K0 PowerOhm
21.00 70644 6778300 PF21R70K6 PowerOhm
20.00 Ohms
20.00 300 13700 T20R300W PG/IPC
20.00 300 18000 PRT20R300W PowerOhm
20.00 400 17900 PR2205-7A PowerOhm
20.00 600 17300 T20R600W PG/IPC
20.00 600 41100 PRT20R600W PowerOhm
20.00 800 41000 PR2205-7 PowerOhm
20.00 900 18500 T20R900W PG/IPC
20.00 900 55000 PRT20R900W PowerOhm
20.00 1200 54900 PR20R1K20 PowerOhm
20.00 1372 87086 222-7A PG/IPC
20.00 1500 28000 T20R1K5 PG/IPC
20.00 1500 224400 PRT20R1K5 PowerOhm
20.00 1600 138400 PR222-7 PowerOhm
20.00 1600 138500 PR20R1K60 PowerOhm
20.00 1860 55084 222-7 PG/IPC
20.00 2250 224400 PR20R2K25 PowerOhm
20.00 2400 87900 PR225-7A PowerOhm
20.00 3063 138493 225-7A PG/IPC
20.00 4000 358900 PR225-7 PowerOhm
20.00 4572 222215 220-7A PG/IPC
20.00 4650 221432 225-7 PG/IPC
20.00 5120 222800 PR20R5K12 PowerOhm
20.00 5940 231100 PRT20R5K94 PowerOhm
20.00 5940 260000 T20R5K94 PG/IPC
20.00 6480 219900 PR220-7 PowerOhm
20.00 7031 169227 220-7 PG/IPC
20.00 8000 297100 PR20R8K00 PowerOhm
20.00 8920 267000 T20R8K92 PG/IPC
20.00 8920 361100 PRT20R8K92 PowerOhm
20.00 10700 548700 PRT20R10K7 PowerOhm
20.00 10700 582000 T20R10K7 PG/IPC
20.00 13520 770000 PR20R13K5 PowerOhm
20.00 15200 924000 T20R15K2 PG/IPC
20.00 15200 1452900 PRT20R15K2 PowerOhm
20.00 16605 825698 440-11A PG/IPC
20.00 20600 1602000 T20R20K6 PG/IPC
20.00 20600 2124800 PRT20R20K6 PowerOhm
20.00 24910 1781970 440-11 PG/IPC
20.00 28400 1066000 T20R28K4 PG/IPC
20.00 28400 4815100 PRT20R28K4 PowerOhm
Ohms Watts Watt Seconds Catalog Manufacturer
