Chapter 4 Selecting An External Resistor for PowerFlex 7-Class Drives
6.00 Ohms
6.00 7776 1086200 PR5505-19A PowerOhm
6.00 12150 1857400 PR5505-19 PowerOhm
6.00 15000 3171800 PR5510-19A PowerOhm
6.00 21600 5176500 PR5510-19 PowerOhm
6.00 28008 1960167 552-19A PG/IPC
6.00 29400 8238200 PR552-19A PowerOhm
6.00 38400 6392400 PR552-19 PowerOhm
6.00 42015 1981674 552-19 PG/IPC
6.00 60000 12900000 PR555-19A PowerOhm
6.00 62551 2135190 555-19A PG/IPC
5.70 Ohms
5.70 1600 8200 PR2205-11A PowerOhm
5.70 1846 61700 PR2205-11 PowerOhm
5.70 2280 90300 PR2210-11A PowerOhm
5.70 3853 212300 PR2210-11 PowerOhm
5.70 4793 449200 PR222-11A PowerOhm
5.70 4938 260816 222-11A PG/IPC
5.70 5836 612000 PR222-11 PowerOhm
5.70 6525 421193 222-11 PG/IPC
5.70 11029 905640 225-11A PG/IPC
5.70 11542 1857400 PR225-11A PowerOhm
5.70 16314 880744 225-11 PG/IPC
5.70 16461 880744 220-11A PG/IPC
5.70 20520 5176500 PR225-11 PowerOhm
5.70 24694 1781970 220-11 PG/IPC
5.70 27930 8238200 PR220-11 PowerOhm
5.40 Ohms
5.40 1200 97000 PR5F4R1K20 PowerOhm
5.40 1382 59900 PR5F4R1K38 PowerOhm
5.40 1670 55700 T5F4R1K67 PG/IPC
5.40 1670 81800 PRT5F4R1K67 PowerOhm
5.40 1749 61700 PR5F4R1K74 PowerOhm
5.40 1949 61700 PR5F4R1K94 PowerOhm
5.40 2680 182900 PRT5F4R2K68 PowerOhm
5.40 2680 185000 T5F4R2K68 PG/IPC
5.40 2856 154800 PR5F4R2K85 PowerOhm
5.40 3650 207900 PR5F4R3K65 PowerOhm
5.40 4541 444300 PR5F4R4K54 PowerOhm
5.40 5080 385200 PRT5F4R5K8 PowerOhm
5.40 5080 401000 T5F4R5K8 PG/IPC
5.40 5529 603100 PR5F4R5K52 PowerOhm
5.40 5780 169000 T5F4R5K78 PG/IPC
5.40 5780 500700 PRT5F4R5K78 PowerOhm
5.40 6998 902500 PR5F4R6K99 PowerOhm
5.40 7280 328000 T5F4R7K28 PG/IPC
5.40 7280 809200 PRT5F4R7K28 PowerOhm
5.40 8640 1540500 PR5F4R8K64 PowerOhm
5.40 12000 699000 T5F4R12K0 PG/IPC
5.40 12000 3328300 PRT5F4R12K0 PowerOhm
5.40 13500 2973600 PR5F4R13K5 PowerOhm
5.40 19440 4904100 PR5F4R19K4 PowerOhm
5.40 20300 738000 T5F4R20K3 PG/IPC
5.40 20300 5451100 PRT5F4R20K3 PowerOhm
5.40 22000 717000 T5F4R22K0 PG/IPC
5.40 22000 5451100 PRT5F4R22K0 PowerOhm
5.40 27993 3607800 PR5F4R27K9 PowerOhm
5.40 34560 6164200 PR5F4R34K5 PowerOhm
5.40 37700 2310000 T5F4R37K7 PG/IPC
Ohms Watts Watt Seconds Catalog Manufacturer
