64 Rockwell Automation Publication PFLEX-AT001L-EN-P - September 2017
Chapter 4 Selecting An External Resistor for PowerFlex 7-Class Drives
4.50 Ohms
4.50 1800 71600 PR2205-12A PowerOhm
4.50 2380 133000 PR2205-12 PowerOhm
4.50 3042 168400 PR2210-12A PowerOhm
4.50 4608 537600 PR2210-12 PowerOhm
4.50 4608 2028300 PR225-12 PowerOhm
4.50 5832 741800 PR222-12A PowerOhm
4.50 6184 152850 222-12A PG/IPC
4.50 8266 239950 222-12 PG/IPC
4.50 9112 1547800 PR222-12 PowerOhm
4.50 13810 660558 225-12A PG/IPC
4.50 16200 4141200 PR225-12A PowerOhm
4.50 20612 1425576 220-12A PG/IPC
4.50 20715 1425576 225-12 PG/IPC
4.50 22050 6407500 PR220-12A PowerOhm
4.50 28800 4794300 PR220-12 PowerOhm
4.50 30918 1486256 220-12 PG/IPC
4.00 Ohms
4.00 8100 1238300 PR4405-19A PowerOhm
4.00 10000 2378800 PR5505-21A PowerOhm
4.00 14400 3623500 PR4405-19 PowerOhm
4.00 19600 5492100 PR5510-21A PowerOhm
4.00 20736 2765900 PR4410-19 PowerOhm
4.00 25600 4394700 PR442-19A PowerOhm
4.00 28207 1321116 442-19A PG/IPC
4.00 32400 5255300 PR5510-21 PowerOhm
4.00 40000 8413000 PR442-19 PowerOhm
4.00 40000 8973900 PR552-21A PowerOhm
4.00 42308 1386961 442-19 PG/IPC
4.00 44057 3441020 552-21A PG/IPC
4.00 57600 14645800 PR445-19A PowerOhm
4.00 66084 1799627 552-21 PG/IPC
3.90 Ohms
3.90 7897 1238300 PR4405-20A PowerOhm
3.90 14040 3623500 PR4405-20 PowerOhm
3.90 24960 4394700 PR4410-20 PowerOhm
3.90 31590 5255300 PR442-20A PowerOhm
3.90 32736 2405659 442-20A PG/IPC
3.90 45489 5531800 PR442-20 PowerOhm
3.90 49108 3246136 442-20 PG/IPC
3.90 62996 8013142 445-19A PG/IPC
3.80 Ohms
3.80 2010 105400 PR2205-13A PowerOhm
3.80 3195 317700 PR2205-13 PowerOhm
3.80 3891 459000 PR2210-13A PowerOhm
3.80 6080 1129600 PR2210-13 PowerOhm
3.80 7227 182571 222-13A PG/IPC
3.80 7695 1238300 PR222-13A PowerOhm
3.80 9500 1982300 PR222-13 PowerOhm
3.80 9788 328491 222-13 PG/IPC
3.80 16139 430346 225-13A PG/IPC
3.80 18620 5176500 PR225-13A PowerOhm
3.80 24089 751149 220-13A PG/IPC
3.80 24212 1321116 225-13 PG/IPC
3.80 24320 3995200 PR225-13 PowerOhm
3.80 36138 2672955 220-13 PG/IPC
3.80 38000 8413000 PR220-13 PowerOhm
Ohms Watts Watt Seconds Catalog Manufacturer
