Accessories and Dimensions Appendix B
7.5 10 25 1.75 13 1321-DC25-4
11 15 32 2.68 21 1321-DC32-2
(1)
15 20 40 2.0 29 1321-DC40-4
(1)
(1) Required on 11 and 15 kW (15 and 20 HP) Frame C Flange Mount drive ratings.
Table 26 - EMC Line Filters
Drive Ratings Catalog Number
Input Voltage kW HP
240V 50/60 Hz 3-Phase 2.2 3.0 22-RF034-CS
4.0 5.0 22-RF034-CS
5.5 7.5 22-RF034-CS
7.5 10 22-RF034-CS
11 15 22-RFD070
15 20 22-RFD100
18.5 25 22-RFD100
22 30 22-RFD150
30 40 22-RFD150
37 50 22-RFD180
480V 50/60 Hz 3-Phase 2.2 3.0 22-RF018-CS
4.0 5.0 22-RF018-CS
5.5 7.5 22-RF018-CS
7.5 10 22-RF018-CS
11 15 22-RF026-CS
15 20 22-RFD036
18.5 25 22-RFD050
22 30 22-RFD050
30 40 22-RFD070
37 50 22-RFD100
45 60 22-RFD100
55 75 22-RFD150
75 100 22-RFD180
90 125 22-RFD208
110 150 22-RFD208
132 200 22-RFD323
160 250 22-RFD480
200 300 22-RFD480
250 350 22-RFD480
Table 25 - Bulletin 1321 - DC Series Bus Inductors – 380...480V, 60 Hz, 3-Phase
kW HP DC Amps Inductance
mh
Watts Loss Catalog Number
IP00 (Open Style)
