132 Rockwell Automation Publication 22C-UM001J-EN-E - January 2017
Appendix B Accessories and Dimensions
132 200 250 375 0.09 231 1321-3R250-B 1321-3RA250-B
160 250 320 480 0.075 264 1321-3R320-B 1321-3RA320-B
200 300 400 560 0.06 333 1321-3R400-B 1321-3RA400-B
250 350 500 700 0.05 340 1321-3R500-B 1321-3RA500-B
5% Impedance
2.2 3.0 8 12 7.5 28 1321-3R8-D 1321-3RA8-D
4.0 5.0 12 18 4.2 41 1321-3R12-C 1321-3RA12-C
5.5 7.5 12 18 4.2 41 1321-3R12-C 1321-3RA12-C
7.5 10 18 27 2.5 43 1321-3R18-C 1321-3RA18-C
11 15 25 37.5 2.0 61 1321-3R25-C 1321-3RA25-C
15 20 35 52.5 1.2 54 1321-3R35-C 1321-3RA35-C
18.5 25 35 52.5 1.2 54 1321-3R35-C 1321-3RA35-C
22 30 45 67.5 1.2 65 1321-3R45-C 1321-3RA45-C
30 40 55 82.5 0.85 71 1321-3R55-C 1321-3RA55-C
37 50 80 120 0.7 96 1321-3R80-C 1321-3RA80-C
45 60 80 120 0.7 96 1321-3R80-C 1321-3RA80-C
55 75 100 150 0.45 108 1321-3R100-C 1321-3RA100-C
75 100 130 195 0.3 128 1321-3R130-C 1321-3RA130-C
90 125 160 240 0.23 138 1321-3R160-C 1321-3RA160-C
110 150 200 300 0.185 146 1321-3R200-C 1321-3RA200-C
132 200 250 375 0.15 219 1321-3R250-C 1321-3RA250-C
160 250 320 480 0.125 351 1321-3R320-C 1321-3RA320-C
200 300 400 560 0.105 293 1321-3R400-C 1321-3RA400-C
250 350 500 700 0.085 422 1321-3R500-C 1321-3RA500-C
Table 24 - Bulletin 1321 - DC Series Bus Inductors - 200...240V, 60 Hz, 3-Phase
kW HP DC Amps Inductance
mh
Watts Loss Catalog Number
IP00 (Open Style)
2.2 3 12 0.92 5 1321-DC12-1
3.7 5 18 0.63 5 1321-DC18-1
5.5 7.5 32 0.85 11 1321-DC32-1
7.5 10 40 0.75 15 1321-DC40-2
Table 25 - Bulletin 1321 - DC Series Bus Inductors – 380...480V, 60 Hz, 3-Phase
kW HP DC Amps Inductance
mh
Watts Loss Catalog Number
IP00 (Open Style)
2.2 3 9 3.68 7 1321-DC9-2
4.0 5 12 2.1 7 1321-DC12-2
5.5 7.5 18 3.75 17 1321-DC18-4
Table 23 - Bulletin 1321-3R Series Line Reactors – 380...480V, 60 Hz, 3-Phase
kW HP Fundamental
Amps
Maximum
Continuous
Amps
Inductance Watts Loss Catalog Number
IP00
(Open Style)
IP11
