142 Rockwell Automation Publication 22C-UM001J-EN-E - January 2017
Appendix B Accessories and Dimensions
Figure 22 - PowerFlex 400 Frame G Drive
Dimensions are in millimeters and (inches)
425.0 (16.73)
381.0 (15.00)
264.0 (10.39)
892.0
(35.12)
819.5
(32.26)
57.5 (2.26)
122.5 (4.82)
302.5 (11.91)
367.5 (14.47)
199.6
(7.85)
244.6
(9.62)
22.0
(0.87)
92.0
(3.62)
