P1 – Floor Level Network (FLN) Appendix G
the fetching of data and a “0” is returned in the Read Value point. See Figure 46
andTabl e 51
.
Figure 46 - Configurable Input Point Operation
Writing Parameter Values
These outputs are written each time the Write Value point is written from the
network.
The Param# for Write Param point’s default to commonly accessed parameters
and can be changed if desired. A value of “0” in the Param# for Write Param
point field disables the writing of data.
Figure 47 - Configurable Objects: Outputs
Table 51 - Configurable Objects: Inputs
Point Name Description Default
36 Read Param Param# to read value 0
37 Read Value Value of parameter specified by Point 36 0
Table 52 - Configurable Objects: Outputs
Point Name Description Default
38 Write Param Param# to write value 0
38 Write Value New value of parameter specified by Point 38 0
Controller Drive
Set Point 36 with
Param# to Read
Data From.
Set Point 37 to get
Data of Param# in
Point 36.
Controller Drive
Set Point 38 with
Param# to Read
Data To.
Write Point 39 to
Write Data to
Param# in
Point 38.
