Rockwell Automation Publication 22C-UM001J-EN-E - January 2017 15
Installation/Wiring Chapter 1
Mounting Considerations
• Mount the drive upright on a flat, vertical and level surface.
• Protect the cooling fan by avoiding dust or metallic particles.
• Do not expose to a corrosive atmosphere.
• Protect from moisture and direct sunlight.
Maximum Surrounding Air Temperature
Frame Screw Size Screw Torque
C M5 (#10-24) 2.45-2.94 N-m (22-26 lb.-in.)
D M8 (5/16 in.) 6.0-7.4 N-m (53.2-65.0 lb.-in.)
E M8 (5/16 in.) 8.8-10.8 N-m (78.0-95.3 lb.-in.)
F M10 (3/8 in.) 19.6-23.5 N-m (173.6-208.3 lb.-in.)
G M12 (1/2 in.) 33.5-41.0 N-m (296.5-362.9 lb.-in.)
H M12 (1/2 in.) 33.5-41.0 N-m (296.5-362.9 lb.-in.)
Frame Enclosure Rating Temperature Range Minimum Mounting Clearances
C IP 20/UL Open-Type -10° to 45°C
(14° to 113°F)
See Figure 1
, Mounting Option A
IP 30/NEMA 1/UL Type 1
(1)
(1) Frame C drives require installation of the PowerFlex 400 IP 30/NEMA 1/UL Type 1 option kit to achieve this rating.
-10° to 45°C
(14° to 113°F)
See Figure 1, Mounting Option B
IP 20/UL Open-Type -10° to 50°C
(14° to 122°F)
See Figure 1, Mounting Option B
D IP 30/NEMA 1/UL Type 1 -10° to 45°C
(14° to 113°F)
See Figure 2
E
FSee Figure 3
GSee Figure 4
H
