Rockwell Automation Publication 22C-UM001J-EN-E - January 2017 149
Accessories and Dimensions Appendix B
Catalog
Number
ABCDEFG
22-RFD323 300 (11.81) 735 (28.94) 145 (5.71) 275 (10.83) 689 (27.13) 64 (2.52) 180 (7.09)
22-RFD480 300 (11.81) 882 (34.72) 145 (5.71) 275 (10.83) 836 (32.91) 64 (2.52) 240 (9.45)
aa
aa
M11
Ø 10.8
(0.43)
45°
A
D
C
F
250
(11.81)
25
(0.98)
60
(2.36)
60
(2.36)
10
(0.39)
50
(1.97)
12.5
(0.49)
6
(0.24)
G
G
G
E
B
M12
ø 9
(0.35)
x 8
3
(0.12)
64
(2.52)
18
(0.71)
Catalog Numbers: 22-RFD323 and 22-RFD480
