Appendix F Metasys N2
Table 41 - Analog Inputs
Network Point Name Description Units Min/Max
Type
(NPT)
Address
(NPA)
AI 1 Feedback Feedback % 0/100
AI 2 Speed d323 [Output RPM] RPM 0/24000
AI 3 Current b003 [Output Current] A 0.00/Rated × 2
AI 4 DC Bus Volts b005 [DC Bus Voltage] V 0/820
AI 5 Last Fault d307 [Fault 1 Code] 1 1/100
AI 6 2nd Fault d308 [Fault 2 Code] 1 1/100
AI 7 Analog In 1 Drive Analog Input #1
(Drive Terminal #13)
%–
AI 8 Analog In 2 Drive Analog Input #2
(Drive Terminal #17)
%–
AI 9 Read Value Read value of Param.
selected by AO 10
Varies by the parameter selected.
AI 10 User In 1 User-defined Input 1
(Param. selected via ADI 1)
AI 11 User In 2 User-defined Input 2
(Param. selected via ADI 2)
AI 12 User In 3 User-defined Input 3
(Param. selected via ADI 3)
AI 13 User In 4 User-defined Input 4
(Param. selected via ADI 4)
Table 42 - Binary Outputs
Network Point Name Description ON (“1”) OFF (“0”)
Type
(NPT)
Address
(NPA)
BO 1 Run Enable Logic Command bit 00 Enable Stop (Coast)
BO 2 Start/Stop Logic Command bit 00 & 01 Start Stop (Normal)
BO 3 Jog Logic Command bit 02 Jog Not Jog
BO 4 Clear Faults Logic Command bit 03 Clear Flts Not Clear Flts
BO 5 Fwd/Rev Logic Command bit 04 & 05 Forward Reverse
BO 6 Not Used Logic Command bit 06 – –
BO 7 MOP Inc Logic Command bit 07 Increment Not Increment
BO 8 Accel 1 Logic Command bit 08 Accel Rate 1 Not Accel 1
BO 9 Accel 2 Logic Command bit 09 Accel Rate 2 Not Accel 2
BO 10 Decel 1 Logic Command bit 10 Decel Rate 1 Not Decel 1
BO 11 Decel 2 Logic Command bit 11 Decel Rate 2 Not Decel 2
To Next Page
