Allen-Bradley B Series User Manual

16 Rockwell Automation Publication 1794-IN082D-EN-P - January 2019
FLEX I/O EtherNet/IP Adapters
Network Status Indicators
Indicator Status Description
Network Status
Indicator
Off –
not powered,
no IP address
Adapter is not powered, or does not have an IP address.
Verify there is power and the adapter is correctly wired
to the power supply.
Make sure the adapter is configured.
Flashing green –
no connections
Adapter has obtained an IP address, but has no
established connections.
Green –
CIP connections
Adapter has an IP address and at least one established
connection.
Flashing red –
connection timeout
One or more of the connections in which the adapter is
the target has timed out.
Red –
duplicate IP address
Adapter has detected that its IP address is already in use.
Configure the adapter with a unique IP address.
Flashing red and green
– self test
Adapter performing power-up self test.
Link Status Indicator
Indicator Status Description
Link Status Indicator
Off –
no link exists
Verify network cabling. Correct as necessary.
Flashing green –
I/O is being
transmitted or
received. Normal operation. No action required.
Steady green –
a link exists
