Bulletin 900-TC
Single-Loop Temperature/Process Controller
3
Bulletin 900 Controllers with Enhanced Features
Both the hardware and function set of the Bulletin 900-TC8 and 900-TC16 temperature controller product lines offer an enhanced feature set
as compared to the 900-TC32. The controller enhancements allow the Bulletin 900-TC8 and 900-TC16 line a much wider range of process
applications. Key enhancements include:
ModBus is a registered trademark of Group Schneider.
• Analog voltage and current inputs
• The combination of thermocouple and platinum RTD controller types into one Global Temperature (GT) controller which incorporates both sensor input types
• A second voltage (SSR) or Triac (electronic relay) control output without loss of an alarm output
• 0...20 mA analog output in addition to the existing 4...20 mA output
• Analog transfer output function to allow easy connection to a strip chart recorder or PLC input
• Manual control of the output from the controller keypad, with bumpless transfer to the Automatic PID mode
• 11-segment alphanumeric LED readouts to display the controller parameters in a more understandable format
• Single- and three-phase heater burnout and short circuit detection
• Faster sampling rate to 250 ms
• Direct connection to your PC's USB port and 4-pin serial port on the controller using the 900-CPOEM1 cable. Allows 1-to-1 (non-network) parameter
configuration and monitoring without the need of an option communication unit/module.
• ModBus
®
RTU (master/slave) protocol
Bulletin 900-TC8 and 900-TC16 Series B Added Features and Functions
In addition to the above enhanced features/functions associated with the Bulletin 900-TC8 and 900-TC16 controllers, the Series B version
(released in October 2008) offers additional features over the series A controllers.
MV (Manipulated Variable) Display Yes No
PF Key (addition to keypad: allows one touch assignment of Auto/Manual, Run/Stop, etc) Yes No
Thermocouple Types: Added W and PL II Yes Yes
Thermocouple Accuracy: Improved from +/-0.5% of PV to +/-0.3% of PV Yes Yes
RTD Accuracy: Improved from +/-0.5% of PV to +/-0.2% of PV Yes Yes
Analog Output Resolution: Expanded from 2,700 to 10,000 Yes Yes
Max. Network Communications Rate: Increased to 57.6 Kbps
Yes7
Yes ‡
Simultaneous Network and USB Cable (900-CPOEM1) communications Yes Yes
Modbus Communications: 1 data, 2-byte mode added Yes Yes
Manipulated Variable Limiter Yes Yes
40% Auto-tuning Yes Yes
Auto-tuning for cooling when heating & cooling is selected Yes
Direct/Reverse mode change selection by input interrupt Yes §
Yes ♣
Square Root extraction function for analog input Yes Yes
PV rate of change alarm Yes Yes
Over current alarm Yes
³ Yes ³
9
Version 1.2 of 900BuilderLite is required to configure Series B controllers if the software configuration option is used versus the controller keypad. NOTE:
Version 1.1 saved parameter cannot be downloaded using Version 1.2
7 Requires the use of a communication option unit: 900-TC8232 (Series B) for RS232C or 900-TC8COM (Series B) for RS485 communications.
‡ Requires the use of a Series B RS485 communication option unit: Refer to Table “Option Units”. NOTE: Series A option units cannot be used with Series B
controllers and vice versa.
§ Requires the use of an event Input option unit: 900-TC8EIM (Series B)
♣ Requires the use of a Series B Event Input option unit: Refer to Table “Option Units”. NOTE: Series A option units cannot be used with Series B controllers and
vice versa.
Yes
New Series B Feature/Functionality
9 900-TC8 900-TC16
Bulletin 900-TC Digital Temperature Controllers
Page 4
Bulletin 900-CONV Interface Converter
Page 23
Bulletin 900 900BuilderLite™ Software
Page 26
Bulletin 900 900Builder™ Software
Page 27
Bulletin 900 — Temperature/Process Controllers
³ Requires the use of a current transformer: 900-CT1 or 900-CT2
