Bulletin 900-TC

Single-Loop Temperature/Process Controller

Product Selection

Bulletin 900-TC8 Controller Models

Bulletin

No.

DIN Size

(DImensions)

(mm)

Sensor Input

Type

Power

Supply

Voltage

Max No. of

Auxiliary

Outputs

Supported

³ Control Output 1 Type Control Output 2 Type

Supports

Heater Burnout

(Open) and

Heater Short-

Circuit Alarm

Controller Cat. No.

900-TC8

1/8 DIN

48 mm (W)

x 96 mm (H)

x 78 mm (D)

Thermocouple

or RTD

100…

240V AC

Relay

—No

900-TC8RGTZ25

— Yes (1-Phase) 900-TC8RGTH1Z25

Voltage (for driving SSR) No 900-TC8RVGTZ25

— Yes (3-Phase)

900-TC8RGTH3Z25

Voltage (for driving SSR)

—No900-TC8VGTZ25

— Yes (1-Phase) 900-TC8VGTH1Z25

Triac ♣

900-TC8VYGTZ25

Voltage (for driving SSR) No 900-TC8VVGTZ25

— Yes (3-Phase) 900-TC8VGTH3Z25

0...20 or 4...20 mA

Analog Output

—No

900-TC8ACGTZ25

Triac ♣

900-TC8ACYGTZ25

Voltage (for driving SSR) No 900-TC8ACVGTZ25

Thermocouple

or RTD

24V

AC/DC

Relay

—No

900-TC8RGTU25

— Yes (1-Phase) 900-TC8RGTH1U25

Voltage (for driving SSR)

—No900-TC8VGTU25

— Yes (1-Phase) 900-TC8VGTH1U25

0...20 or 4...20 mA

Analog Output

—No

900-TC8ACGTU25

Analog Current

& Voltage 0...20

and 4...20 mA

0...5, 1...5, and

0...10V DC

100…

240V AC

Relay — Yes (1-Phase)

900-TC8RABH1Z25

Relay — No

900-TC8RABZ25

Voltage (for driving SSR) — Yes (1-Phase)

900-TC8VABH1Z25

Voltage (for driving SSR) — No

900-TC8VABZ25

Voltage (for driving SSR)

Triac ♣

900-TC8VYABZ25

0...20 or 4...20 mA

Analog Output

—No

900-TC8ACABZ25

Bulletin 900-TC16 Controller Models

Bulletin

No.

DIN Size

(DImensions)

(mm)

Sensor Input

Type

Power

Supply

Voltage

Max No. of

Auxiliary

Outputs

Supported

³ Control Output Type §

Supports Heater

Burnout (Open)

and Heater

Short-Circuit

Alarm

Controller Cat. No.

900-TC16

1/16 DIN

48 mm (W)

x 48 mm (H)

x 78 mm (D)

Thermocouple

or RTD

100…

240V AC

Relay Output Yes‡

900-TC16RGTU25

Triac ♣

Yes‡

900-TC16YGTZ25

Voltage output (for driving SSR) Yes‡ 900-TC16VGTZ25

0...20 or 4...20 mA Analog Output No 900-TC16ACGTZ25

Thermocouple

or RTD

24V

AC/DC

Relay Output Yes‡

900-TC16RGTU25

Voltage output (for driving SSR) Yes‡ 900-TC16VGTU25

0...20 or 4...20 mA Analog Output No 900-TC16ACGTZ25

Analog Current

& Voltage 0...20

and 4...20 mA

0...5, 1...5, and

0...10V DC

100…

240V AC

Relay Yes ‡

900-TC16RABZ25

Triac ♣

Yes ‡

900-TC16YABZ25

Voltage (for driving SSR) Yes ‡

900-TC16VABZ25

0...20 or 4...20 mA Analog Output No

900-TC16ACABZ25

24V

AC/DC

Relay Yes ‡

900-TC16RABU25

Voltage (for driving SSR) Yes ‡ 900-TC16VABU25

0...20 or 4...20 mA Analog Output No

900-TC16ACABU25

9 A current transformer (CT) is not provided with the unit.

7 When the heating and cooling function or the heater burnout alarm is used, one of the relay alarm outputs can be used as the heating or cooling output or

heater burnout alarm.

‡ To implement the single-phase or three-phase heater burnout and heater short alarm function, an option module must be inserted into the 900-TC16 controller.

For a list of 900-TC16 option modules, refer to the Option Units table, page 6. The heater burnout and heater short alarm is available by mounting the

appropriate option module into any 900-TC16 controller that supports (yes) the heater burnout (open) or heater short-circuit feature.

§ The Bulletin 900-TC16 can have a second ON/OFF control output (SSR) by adding an option unit to the controller. Refer to Option Units table on page 6.

♣ For AC voltage operation only

³ Typically used for alarms or cooling output in a heat/cool application
