2 ControlLogix DC (10-30V) Sourcing Input Module
Publication 1756-IN006A-EN-P - December 2000
• visiting www.theautomationbookstore.com and placing
an order
• calling 800.963.9548 (USA/Canada) or 001.320.725.1574
(outside USA/Canada)
Identify the Module Components
You received the following components with your order:
• 1756-IV16 module
• Removable Terminal Block (RTB) door label
If you did not receive these components, contact your Rockwell
Automation sales office.
This module mounts in a ControlLogix chassis and uses a
separately-ordered RTB or a Bulletin 1492 Interface Module (IFM) to
connect all field-side wiring.
This module uses one of the following RTBs:
• 1756-TBNH 20 position NEMA RTB
• 1756-TBSH 20 position Spring Clamp RTB
Use an extended-depth cover (1756-TBE) for applications with heavy
gauge wiring or requiring additional routing space. When using an
IFM, consult the documentation that came with it to connect
all wiring.
IMPORTANT
Before you install your module, you should
have already:
• installed and grounded a 1756 chassis and
power supply.
• ordered and received an RTB or IFM and its
components for your application.
