Allen-Bradley ControlLogix 5580

Rockwell Automation Publication 1756-RM100F-EN-P - October 2018 159
Diagnostics and Status Indicators with CompactLogix Systems Chapter 8
Ethernet Port A1/A2 Web Pages
The Ethernet Port A1/A2 web pages use a series of tabs to provide information
about the following:
•Diagnostic Overview
•Network Settings
•Ethernet Statistics
Dual-IP Mode
Linear/DLR Mode
