Allen-Bradley ControlLogix 5580 - Controller Dimensions; Compactlogix 5370 L3 Dimensions; Compactlogix 5380 Dimensions

Rockwell Automation Publication 1756-RM100F-EN-P - October 2018 53
Replacement Considerations with CompactLogix and Compact GuardLogix Systems Chapter 3
Controller Dimensions
This section shows dimensional differences.
CompactLogix 5370 L3 Dimensions
CompactLogix 5380 Dimensions
118.00 mm
(4.65 in.)
105.00 mm
(4.13 in.)
55.00 mm
(2.17 in.)
132.00 mm
(5.20 in.)
98.10 mm
(3.86 in.)
137.84 mm
(5.43 in.)
123.00 mm
(4.84 in.)
144.01 mm
(5.70 in.)
136.81 mm
(5.39 in.)
130.31 mm
(5.13 in.)
101.66 mm
(4.00 in.)
