Allen-Bradley ControlLogix 5580

56 Rockwell Automation Publication 1756-RM100F-EN-P - October 2018
Chapter 3 Replacement Considerations with CompactLogix and Compact GuardLogix Systems
Compact GuardLogix 5370 Compact GuardLogix 5380
SAFETY
L36ERMS
CPU
SFTY RUN
SFTY TASK
SFTY LOCK
SFTY OK
Guard
Compact
Logix
Guard
Compact
Logix
1 (Front)
2 (Rear)
Item Description
1 Status Indicators
2 Behind the door:
• RUN REM PROG mode switch
• Reset button
•SD card slot
3USB port
4Ethernet ports 1 and 2
1
3
2
4
1
9
4
3
5
7
2
Item Description
14-character display
2 Controller Status Indicators
3USB port
4 Ethernet ports 1 and 2
5 Power Status Indicators
6 EtherNet/IP Status Indicators
7 MOD power connection
8 Behind the door:
• RUN REM PROG mode switch
• Reset button
•SD card slot
9 SA power connection
6
8
