PanelView Plus and PanelView Plus Compact 400 and 600 Terminals 13
Publication 2711P-IN002G-EN-P - November 2009
Product Dimensions
The illustrations show approximate product dimensions for the PanelView Plus and
PanelView Plus Compact 400 and 600 terminals. Measurements are in mm (in.).
400 Terminal Dimensions
60
(2.35)
90
(3.54)
152
(6.0)
185
(7.28)
154 (6.08)
71 (2.81)
400 Keypad or
Keypad and Touch
