PanelView Plus and PanelView Plus Compact 400 and 600 Terminals 23
Publication 2711P-IN002G-EN-P - November 2009
Check the Display
If the terminal display is dim or unreadable:
• check the brightness setting. From terminal Configuration mode, choose Terminal
Settings>Display Intensity.
• check the contrast setting. From terminal Configuration mode, choose Terminal
Settings>Display Contrast.
• check the Screen Saver settings. The backlight may turn off or dim the display
unexpectedly. From terminal Configuration mode, choose Terminal
Settings>Display>Screen Saver.
Startup Information Messages
Startup information messages display in a specific sequence on the terminal screen during
startup and typically display for a few seconds. These messages do not require that you
perform any action.
Message # Message Description
30 Watchdog Test Tests the watchdog circuitry to verify system integrity.
1 RAM Test Tests the RAM memory.
2 Image Search Checks for new OS firmware upgrade on the external compact flash
card and the serial port.
11 Downloading Image Transfers a new OS firmware upgrade to internal RAM. Message may
remain on screen for several minutes.
20 Transfer Image Programs the OS firmware just downloaded into RAM. Message may
remain on screen for several minutes.
24 CRC Check Checks the integrity of the OS firmware.
27 Decompress System Decompresses the compressed OS firmware into RAM.
28 Starting System Launches the operating system (OS).
29 System Check ### Internal file system integrity check (### is percent progress indicator).
29.1 System Check Internal file system check disabled. Contact technical support.
