PanelView Plus and PanelView Plus Compact 400 and 600 Terminals 27
Publication 2711P-IN002G-EN-P - November 2009
Dimensions (HxWxD), approx.
400 keypad, or keypad and touch 152 x 185 x 90 mm (6.0 x 7.28 x 3.54 in.)
600 keypad, or keypad and touch 167 x 266 x 98 mm (6.58 x 10.47 x 3.86 in.)
600 touch 152 x 185 x 98 mm (6.0 x 7.28 x 3.86 in.)
Weight, approx.
400 keypad
(1)
, or keypad and touch
635 g (1.40 lb)
600 keypad, or keypad and touch
(1)
930 g (2.05 lb)
600 touch
(1)
789 g (1.74 lb)
General
Battery life 5 year min at 77 °F (25 °C)
Clock Battery backup, + /- 2 minutes per month
Status indicators COMM (Green), Fault (Red)
Application flash memory 20 MB
External compact flash storage 512 MB max
(1)
Add approximately 95 g (0.21 lb) for communication module.
Environmental Specifications
Attribute Value
Temperature, operating 0…55 °C (32…131 °F)
Temperature, storage -25…70 °C (-13…158 °F)
Heat dissipation 80 BTU/hr
Altitude, operating 2000 m (6561 ft)
Vibration 10…57 Hz, 0.012 pk-pk displacement
57…500 Hz 2.0 g pk acceleration
Shock, operating 15 g at 11 ms
Shock, nonoperating 30 g at 11 ms
Relative humidity 5…95% without condensation
Enclosure ratings NEMA Type 12, 13, 4X (indoor use only), IP54, IP65
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals
