PowerFlex 700 Dimensions 1-19
5
75 HP,
480V
(55kW,
400V)
Normal
Duty
Drive
100 HP,
480V
Normal
Duty
Drive
6
All
Frame Rating Dimensions in millimeters and (inches)
96.0
(3.78)
159.5
(6.28)
184.0
(7.24)
220.0
(8.66)
229.5
(9.04)
241.9
(9.52)
45.0 (1.77)
85.0 (3.35)
93.2 (3.67)
104.0 (4.09)
150.0 (5.91)
215.0 (8.46)
255.0 (10.04)
28.0 (1.10)
22.2 (0.87) Dia.
2 Places
62.7 (2.47) Dia.
2 Places
34.9 (1.37) Dia.
2 Places
96.0
(3.78)
153.5
(6.04)
184.3
(7.26)
188.5
(7.42)
223.5
(8.80)
241.9
(9.52)
44.0 (1.73)
66.4 (2.61)
31.9 (1.26)
42.6 (1.68)
128.0 (5.04)
232.3 (9.15)
28.0 (1.10)
22.2 (0.87) Dia.
2 Places
62.7 (2.47) Dia.
2 Places
Removable Junction Box
34.9 (1.37) Dia.
116.6
(4.59)
148.5
(5.85)
222.3
(8.75)
242.0
(9.53)
219.0
(8.62)
185.4
(7.30)
151.8
(5.98)
52.1 (2.05)
69.1 (2.72)
130.1 (5.12)
280.1 (11.03)
330.1 (13.00)
230.1 (9.06)
47.1 (1.85)
45.6 (1.80)
56.2 (2.21)
Removable Junction Box
22.2 (0.87) Dia.
4 Places
62.7 (2.47) Dia.
3 Places
34.9 (1.37) Dia.
3 Places
