Allen-Bradley PowerFlex 700AFE Installation Instructions

Rockwell Automation Publication 750-IN100B-EN-P - July 2017 81
Mechanical and Electrical Installation Chapter 4
LCL Module Connections
1. Disconnect the AC input fuse wire harness connector P5 and the
240 volt connector P4 on the LCL filter module. See Figure 44
.
Figure 44 - LCL Filter Wiring Harnesses
Power Control Bus AC Fuse
P5
P1
P4
P2
