P216 Anlg Out2 Scale RW x:88…89 Anlg Out1 DataHi, Anlg
Out1 DataLo
RW
P217 Anlg Out 1 Setpt RW x:76 Anlg Out0 Stpt RW
P218 Anlg Out 2 Setpt RW x:86 Anlg Out1 Stpt RW
(1) With 2262C-2R or 2262D-2R -Series I/O Module. The 'x' in the Port:Parameter.Bit column is the physical port where the I/O
module is installed.
Table 36 - Digital I/O Parameter Comparison
PowerFlex 700AFE Bus Supply PowerFlex 755TM Bus Supply
(1)
(1) With 2262C-2R or 2262D-2R -Series I/O Module. The 'x' in the Port:Parameter.Bit column is the physical port where the I/O
module is installed.
Parameter,
Bit
Display Name Read/
Write
Port:Parameter.Bit Display Name Read/
Write
P221…P226 Digital Inx Sel RW 0:105,112,119,123 DI L Enable, DI L Stop, DI
L Start, DI L Run
RW
P229 Digital Out2 Sel RW x:10 RO0 Sel RW
P230 Dig Out2 Invert RW x:6.0 Dig Out RO0 Invert RW
P233 Digital Out3 Sel RW x:20 RO1 Sel RW
P234 Digital Out3 Invert RW x:6.1 Dig Out RO1 Invert RW
Table 37 - Communication Parameter Comparison
PowerFlex 700AFE Bus Supply PowerFlex 755TM Bus Supply
Parameter,
Bit
Display Name Read/
Write
Port:Parameter.Bit Display Name Read/
Write
Port 5,
P04…07
IP Addr Cfg 1, 2, 3, 4 RW 0:302…305 IP Addr Cfg 1, 2, 3, 4 RW
Port 5,
P08…P11
Subnet Cfg 1, 2, 3, 4 RW 0:306…309 Subnet Cfg 1, 2, 3, 4 RW
P170…P177 Data In RW 0:321…336 DL From Net RW
P180…P187 Data Out RW 0:340…355 DL To Net RW
Table 35 - Analog I/O Parameter Comparison (Continued)
PowerFlex 700AFE Bus Supply PowerFlex 755TM Bus Supply
(1)
Parameter,
Bit
Display Name Read/
Write
Port:Parameter.Bit Display Name Read/
Write
