Preface
Additional Resources
These documents contain additional information concerning related products
from Rockwell Automation.
Resource Description
PowerFlex Active Front End User Manual, publication 20Y-
UM001
Provides basic information that is needed to install,
start-up, and troubleshooting of IP20/IP21 enclosed
PowerFlex 700AFE bus supplies.
Provides detailed technical data, specifications,
ratings, and option information.
Provides detailed parameter descriptions,
configuration settings, and fault/alarm
troubleshooting.
Lifting and Mounting PowerFlex Active Front End (AFE) –
Frames 10 and 13 Installation Instructions,
publication 20Y-IN001
Provides detailed installation instructions for
handling IP20/IP21 enclosed PowerFlex 700AFE bus
supplies.
PowerFlex 700AFE Firmware v1.003 Release Notes,
publication 20Y-RN001
Firmware Release Notes for PowerFlex 700AFE bus
supply.
PowerFlex Active Front End Solutions Product Profile,
publication 20Y-PP001
Provides an overview of product benefits and
features.
PowerFlex Active Front End – Frame 10 Hardware Service
Manual, publication 20Y-TG001
This manual contains hardware service information
for the frame 10 PowerFlex Active Front End.
PowerFlex Active Front End – Frame 13 Hardware Service
Manual, publication 20Y-TG002
This manual contains hardware service information
for the frame 13 PowerFlex Active Front End.
PowerFlex Active Front End in IP20 2500 MCC Style Encl. Fr.
10 Bus Splice Kit Installation Instructions,
publication 20Y-IN003
Provides detailed installation instructions for MCC bus
splice kit.
PowerFlex Active Front End in IP20 2500 MCC Style Encl. Fr.
13 Right-Side Bus Splice Kit Installation Instructions,
publication 20Y-IN004
Provides detailed installation instructions for MCC bus
splice kit.
PowerFlex Active Front End in IP20 2500 MCC Style Encl. Fr.
13 Left-Side Bus Splice Kit Installation Instructions,
publication 20Y-IN005
Provides detailed installation instructions for MCC bus
splice kit.
PowerFlex 700AFE Spare Parts Installation Instructions,
publication 20Y-IN002
Provides detailed installation instructions for
PowerFlex 700AFE spare parts.
PowerFlex 700H, 700S, and 700AFE Drive Fan Systems,
Frames 9…14 Installation Instructions,
publication PFLEX-IN029
Provides detailed installation instructions for cooling
fan replacement and installation.
Balancing Resistor Kit for 600/690V Frame 13 PowerFlex
700AFE and 600/690V Frame 13 and 14 PowerFlex 700H/
700S AC Drives Installation Instructions, publication
PFLEX-IN028
Provides detailed installation instructions for
balancing resistor replacement.
PowerFlex 750-Series Products with TotalFORCE Control
Technical Data, publication 750-TD100
Provides detailed technical data, specifications,
ratings, fuse/circuit breaker sizing and option
information for IP20/IP54 enclosed PowerFlex 755T
products.
PowerFlex 750-Series Products with TotalFORCE Control
Installation Instructions, publication 750-IN100
Provides procedures for the handling, installation,
and electrical wiring of IP20/IP54 enclosed PowerFlex
755T products.
PowerFlex 755TM IP00 Open Type Kits Technical Data,
publication 750-TD101
Provides detailed technical data, specifications,
ratings, fuse/circuit breaker sizing and option
information for IP00 open type PowerFlex 755T drive
system products.
PowerFlex 755TM IP00 Open Type Kits Installation
Instructions, publication 750-IN101
Provides procedures for the handling, installation,
and electrical wiring of IP00 open type PowerFlex
755T drive system products.
PowerFlex Drives with TotalFORCE Control Programming
Manual, publication 750-PM100
Provides detailed parameter descriptions,
configuration settings, and fault/alarm
troubleshooting.
